Clauberg CC 2/ 2 Web Offset Printing Press – Sold

Clauberg CC 2/ 2 Book Press

Printing Configuration:

1/1 – colour print with Non-stop plate change.

2/2 – colours with conventional plate change when machine is stationary

Reel diameter: 1250 mm maximum

Printing web width: 796 mm maximum

Cylinder circumference: 1020 mm

Cut-off: 2 x 510 mm

Maximum page height: 244 mm (trimmed)

Printable page height: 240mm, can be printed with print to bleed of the head and foot of the page.

Sheet size: 820 x 1062 mm (printing width – 796 mm.)

Substrates: 28 GSM to 120 GSM to 1.5 – fold volume

Folded products:

32pp signature with perforation for adhesive bond

32pp signature with special perforation for thread stitching

24pp signature with perforation for adhesive bond

24pp signature with special perforation for thread stitching

16pp signature with perforation for adhesive bond

16pp signature with special perforation for thread stitching

8pp signature with perforation for perfect binding; half volume in the pressure; singling

8pp signature without perforation for thread stitching

Comprising of:

(1) MEG Automatic Flying Splice Reelstand

(2) Clauberg Blanket to Blanket Web Offset Printing units.

(1) Infra-Red dryer

(1) Clauberg Collect/Non-collect Folder.

(1) Silicone Applicator.

(1) Conveyor equipment and Gammerler semi-automatic stacking unit
